YRKK Series High Voltage Three-Phase Slip ring Motors

    • * Frame sizes: 355-1000
      * Rated output: 185-5000kW
      * Insulation class: F
      * Degree of protection:IP44 / IP54 / IP55
      * Enclosure: IC611
      * Rotor: Wound rotor with collector rings
      * Voltage: 6Kv, 10Kv
      * Mounting: Horizontal
    • Hotline:
      +86-0563-5031948
    • Fax:
      +86-0563-5028878
    • Download:





    YRKK Series Medium size H355-560 Documentation

    YRKK Series Large size H710-1000 Documentation





    This motor can be processed by the anticorrosion anti-mould-proof process to derive outdoor (W) and outdoor corrosion protection (WF) motors.

    High efficiency and energy saving.

    Low vibration.

    Reliable performance.

    Easy installation and maintenance.

    The frame is made of steel plate being welded up into form of square tank shape with light weight and firm rigidity.

    Stator is an outer-press-assembly structure.

    The stator winding is F grade insulation at the winding’s end part being firm banded.

    The whole stator and rotor has been treated with VPI technology to make stator and rotor with insulation and moisture resistance.

    Silver brazing is used between rotor coils and between copper strip and coils to ensure the reliability of motor operation.



    General purpose including machine tool, compressor, water pump, ventilator, conveyor, crushing mill,  It is also used as the primitive for the mechanical industry. petroleum industrypower plant and so on.





    Common frame size corresponding to the power:

    6kV 50Hz

    Frame Size 355 400 450 500 560 630 710 800 900 1000
    Power range kW 185~220 185~400 185~630 220~1000 355~1400 500~2000 500~3150 800~4500 1250~4000 1800~5000
    Poles 4 4.6.8

    4.6.8.

    10.12

    4.6.8.

    10.12

    4.6.8.

    10.12

    4.6.8.

    10.12

    4.6.8.

    10.12.16

    4.6.8.

    10.12.16

    8.10.12.16 10.12.16





    10kV 50Hz

    Frame size - - 450 500 560 630 710 800 900 1000
    Poles - - 4.6 4.6.8.10 4.6.8.10.12 4.6.8.10.12 4.6.8.10.12.16 4.6.8.10.12.16 6.8.10.12.16 8.10.12.16
    Power range kW - - 220~450 220~800 220~1120 400~1600 500~2800 710~4500 1120~4500 1600~4500

    Remark: For the other special rated powers, please contact with us.
